Architecture + Constructability
Our Building Projects
THE FORUM-TRUE BLUE COMMERCIAL PLAZA
Project Location: True Blue, Grand Anse, St. George's, Grenada
Project Type: Commercial
Project Scale: 13,000 Sq. Ft. Building
Project Status: Pre-Approved for Construction, Client Opted for Temporary Container Structure (Dynamic Latitude prepared drawing for temporary approval)
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Not Appointed
Client: Confidential
Visualization Artist: Undisclosed
Contractor: To be determined
Project Description:
The Forum is designed to be a 13,000 Sq. Ft. commercial building with rentable units in a “C” formed layout, enclosing a partially covered plaza with dining and seating. This building comprises of a public car park, separate administrative parking and a ring road to accommodate back of house functions. The superstructure is to be of reinforced concrete and roofing is to be of steel trusses, metal purlins and insulated corrugated metal roof sheeting. The major challenges of this project would be the degree of excavation as of a matter of practicality this building would have to sit level slightly elevated above the public road on what is currently a sloping site.
VILLA | EUNICA @ FORTE JEUDY LOT 10
Project Location: Forte Jeudy,, St. George's, Grenada
Project Type: Residential
Project Scale: 4,000 Sq. Ft. Building
Project Status: Under construction
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Lachaba Carr Joseph
Contractor: Leo Peters, Lap Design & Construction Ltd.
Project Description:
This 4,400 Sq. Ft. residence with large pool is to be situated on the very end of the Forte Jeudy coastal bluff with panoramic ocean view. Dynamic Latitude has been involved in this project from land acquisition and is involved in the construction supervision of this project. This project in terms of design vernacular is one of the crowning projects of our studio and defines our architectural perspective.
This three bedroom residence counts with spacious rooms, garage, large driveway, loft floor and several covered and uncovered external courtyards, living area and services areas. For the owners, the view is more important than the dwelling itself and all fenestration to the west is open to the view with laminated glass and overhangs shading from heat gain. This residence was conceived in 3 separate blocks at owners request being master, living and guest blocks. It is a truly minimalistic work of art with the integration of concrete, wood and local stonework.
OFFICE BUILDING @ GRAND ANSE
Project Location: Grand Anse, St, George's, Grenada
Project Type: Commercial
Project Scale: 12,200 Sq. Ft
Project Status: Approved for Construction
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: John Adams Engineering
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor / Project Coordinator: Leo Peters, Lap Design & Construction Ltd.
Project Description:
This is an office building for the practice of a prominent Grenadian professional. Collaborative design effort with local contractor / designer of note.
As this project is confidential in nature no further description can be given.
PRINCETON PASSIVE HOUSE
Project Location: Princeton, NJ, USA
Project Type: Residential
Project Scale: 5,000 Sq. Ft. Building
Project Status: Marketing & Real Estate, Not realized
Architect: Doug R. Schotland
Visualization Artist: Lachaba Carr Joseph
Project Description:
Dynamic Latitude was engaged to work along with Doug R. Schotland Architects of Pennington, New Jersey to formally design this first contemporary home design for their firm. Our studio's role in this project was to undertake lifelike 3D renderings and interior styling. This large home yet modest for Princeton is 5,000 Sq. Ft. over two level and is to be situated on 2 acres of land with large trees in excess of 100 feet. This project although not being built was a success on our end as the visualization aided in the marketing and real estate for this dwelling and aid an accomplished traditional American architect to realize his first contemporary home design. This home is intended to have passive sustainable features with regards to the glazing to reduce energy consumption and carbon footprint.
MULTI UNIT RESIDENCE @ HILL TOP
Project Location: Calivigny, St. George's, Grenada
Project Type: Residential
Project Scale: (3) Unit Multi-Family Dwelling
Project Status: Prepared for Submission for Approval
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Novara Engineering
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: To be determined
Project Description: Calivigny Hilltop Lot #32 Multi-Unit Residence overlooking Westerhall Main Road. This project constitutes a demolition of an existing home damaged during Hurricane Ivan and newly proposed three storey contemporary residential building overlooking the Westerhall coastline.
RESIDENCE @ FORTE JEUDY LOT 152
Project Location: Forte Jeudy, St. George's, Grenada
Project Type: Residential
Project Scale: 4,000 Sq. ft.
Project Status: ON THE DRAWING BOARD
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: To be determined
Project Description:
This (4) bedroom residence is a primarily a of a single storey with the rear of the comprising of a guest flat with an upper bedroom level. The design of this dwelling was done to conform with the home owner’s development regulations within the development which conditionally restricts two storey dwelling. The design aesthetic is generally contemporary with a complimentary traditional Bermuda profiled roof above the garage.
MABOUYA VUE VILLA @ ST. LOUIS CARRIACOU
Project Location: St. Louis, Carriacou, grenada
Project Type: Residential
Project Scale: 5.200 Sq. Ft.
Project Status: Under Construction
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: Kevin Richardson (Bald Head)
Project Description:
This project consist of two separate entries, one at the upper level allowing for a single car access and turn and another at the lower level, which allows for a two car guest parking and two car garage. This dwelling also counts with a sky lounge which is at a mezzanine level above and open plan living/kitchen. Most significantly in counts with a 12 foot wide suspended wooden wrap around veranda with access from two of the three bedrooms including the master bedroom. The upper wood framed roof extends South to North from the ground to the ridge to avoid uplift from hurricane force winds. Further bracing is employed on this roof to all allow for stability from lateral wind loads. This feature also allow for a visual of landscaped areas to the rear of the site from the foyer and sky lounge. The roof finish on the wooded framed roofs are of a traditional finish of synthetic cedar shingles. This dwelling also counts with a lower concrete roof allowing for the installation of solar panels and rain harvesting. More precisely all roofs on this dwelling will be used for rain harvesting, allowing for a substantial area. The cistern is dual in nature to allow for maintenance of one at a time without having to dispose of all the water supply. This cistern will hold close to 24,000 gallons of water beyond the minimum government recommended 11,000 gallons. Additionally this dwelling counts with a great deal of covered semi-outdoor spaces for entertaining guest on the lower level. Finally the fenestration is a simple combination of glass panels with operable vertical louvers with mosquito screens. This dwelling aims to mix a clean lined contemporary vision with the tropical and traditional warmth with material choice and volumetric gestures.
TRUE BLUE COMBAT CENTER
Project Location: True Blue, Grand Anse, St. George's, Grenada
Project Type: Commercial
Project Scale: 20,000 Sq. Ft. Building
Project Status: Pre-Approval Denied, Not realized
Architect: Lachaba Carr Joseph
Client: Confidential
Project Description:
This Combat Center was intended to be an exclusive tropical get away for professional martial artist. This would have not only included a state of the art training center but additionally 26 luxury rooms to accommodate two teams at a given moment. The site counts with a sea view, beach access and is adjacent to the airport runway. Unfortunately this project could not be proceeded with or rectified due to potential breach of airport regulations.
RESIDENCE @ EGMONT 208
Project Location: Egmont, St. George's, Grenada
Project Type: Residential
Project Scale: : 3,700 Sq. Ft. Building
Project Status: Under Construction
Architects: Lachaba Carr Joseph & Confidential Client
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: None
Contractor: Benadict Clyne
Project Description: This sizable three storey building sits on a small costal lot of 9,700 Sq. Ft. The design of this project is a collaborative effort with the client who are Architect & Climate Science Professor in Virginia. This project went through the conceptualization of 5 different contemporary design concepts before one was settled on. Dynamic Latitude was responsible for project planning, approval, costing and construction supervision all from client's digital 3D model and space plan of this contemporary home design. This project counts with some interesting architectural features such as a 7' cantilevered vanishing edge plunge pool, entry bridge, lower roof top parking, suspended wooden deck, court yard and shore front wooden deck.
RESIDENCE @ SEA VIEW DRIVE-LANCE AUX EPINES
Project Location: Lance Aux Epines, St. George's, Grenada
Project Type: Residential
Project Scale: 3,500 Sq. Ft. Dwelling
Project Status: Submitted for Building Approval
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Mrs. Noda, Novara Engineering
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: To be determined
Project Description: This is a (4) bedroom minimalistic contemporary shore front home to be built in Lance Aux Epines. This spaces and building aesthetic are very simple and modest yet spacious and aerated. The design accommodates for traditional fenestration with louvered bathrooms and interior shuttering system. Along with the incorporation of skylights this home is very illuminated and is to be finished on the interior with light pastel colors. The land is relatively flat with a slight gradient towards a rocky shore line. This property counts with incredible sea side vistas and makes full use of this with an infinity edge pool and uncovered roof top space with internal stair access.
EGMONT BAY VILLA
Project Location: Petite Calivigny, St. George's, Grenada
Project Type: Residential
Project Scale: Two 2,600 Sq. Ft. Buildings
Project Status: Built
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: Kishure Fletcher, Caribbean Ideal Designs Architecture & Construction Services Ltd (Phase 1)
Project Description:
This residence is located in Petite Calivigny on the outskirt of the Egmont Development. Dynamic latitude was involved in this project throughout the land acquisition and design and planning. Approvals were received for the construction to two small villas on a 10,000 Sq. Ft. Subdivided lot. Due to several hiccups during the construction, some design alterations were made to accommodate budget and owners preferences. Ultimately this property would contain a single dwelling with outdoor space and amenities.
RESIDENCE @ EMGONT 299
Project Location: Egmont Development, St. George's, Grenada
Project Type: Residential
Project Scale: 5,000 Sq. Ft. Over Three Levels with Roof Top Deck
Project Status: Submitted for Building Approval
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Reinier Noda, Novara Engineering
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: To be determined
Project Description:
This design is of minimalistic contemporary approach, with a clean lined approach to design. This approach principally enforced wall alignments and some degree of symmetry. An open fenestration was taken to the view side only to consolidate the cost of impact resistant glazing. Privacy and minimal fenestration was maintained to the front and laterally.
The design aesthetics further embrace a “White Architecture”, absent of any loud building colors with a minimal use of natural elements such as locally supplied hardwood. This approach allows for a clean pallet to allow for the interior decor and landscaping to define the sensibility of spaces specific to the occupants style. As such the architecture although being interesting in geometry becomes the item which frames and accommodates the features which gives character of the dwelling.
RESIDENCE @ EGMONT 301
Project Location: Egmont, St. George's, Grenada
Project Type: Residential
Project Scale: 3,200 Sq. Ft.
Project Status: Under Construction
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: Brian Andrews
Project Description:
This dwelling has been conceived with the collaboration with the client who is a successful foreign Electrical Engineer. Having looked at the topography, views and spatial requirement the client took the first leg of the design, even going so far as to obtain development approval and do his own digital 3D model. Once Dynamic Latitude was approached for the planning and further approvals for this project, it was accepted on the basis that the facades, volumes and general architectural appearance of the project would be redesigned to a more contemporary vernacular, while for the most part keeping the client's preferred layout. It must be stated that from a planning and collaborative approach this project was a success, Dynamic Latitude recognized the client's specific expertise in design of building services and the client recognized the specific architectural and planning knowledge that was imparted to make improvements to the initial concept.
RESIDENCE @ WESTERHALL
Project Location: Westerhall, St. David's, Grenada
Project Type: Residential
Project Scale:7,000 Sq. Ft.
Project Status: ON THE DRAWING BOARD
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor / Project Coordinator: Leo Peters, Lap Design & Construction Ltd.
Project Description:
This project is a large contemporary dwelling for a prominent Grenadian professional and family residence.
As this project is confidential in nature no further description can be given.
RESIDENCE @ EGMONT 302
Project Location: Egmont, St. George's, Grenada
Project Type: Residential
Project Scale: 2,000 Sq. Ft. Building
Project Status: Built
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: None
Contractor: Self built
Project Description:
This dwelling marks the third home design done for this client in Grenada. Working along with the client’s design impetuous this 2,000 Sq. Ft. house was designed to be cost effect yet allow for proper air flow and to still capture the view without excessive glazing. The home was also designed in the most simplistic manner for the easy of drawing interpretation and construction. Most impressively having learnt on previous homes the construction process, the owner took on the role of builder for this home and was able to build at an astonishingly low cost with good quality finishes.
YING YANG RESIDENCE @ WOBURN
Project Location: Mt. Prospect, Woburn, St. George's, Grenada
Project Type: Residential
Project Scale: 3,000 Sq. Ft. Building
Project Status: Approved for Construction, Not active
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Adrian Prince (United Kingdom)
Contractor: To be Determined
Project Description:
This two bedroom home perched on top of a hill with steep access road overlooks Worburn Bay. It was critical to maintain panoramic views and the circular shaped living space facilitated this requirement. This home not only contains curves from a functional perspective but indeed aims to satisfy an artistic requirement of the owner, who is himself is an Art Director. Therefore a great deal of the design impetus stems from the owner’s artistic premise and articulated by Dynamic Latitude. This home is truly a merge of Art Deco and contemporary architecture.
RESIDENCE @ POINT MARQUIS DEVELOPMENT LOT 43
Project Location: Point Marquis Development, St. David's, Grenada
Project Type: Residential
Project Scale: 2,000 Sq. Ft.
Project Status: Approved for Construction
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: To be determined
Project Description:
This 2,000 Sq. Ft. dwelling located near La Sagesse in on of the most secluded and beautiful private gated community would be one of the first five homes to be completed in this development. The design is very minimalistic with a simple layout for easy of building to conserve budget. Although modest in size and budget this home is expected to be one of the most impacting homes to be built at this location because of the lot visibility and uniqueness of design divorced from the usual features Grenadian housing. Although contemporary in design this home still embraces traditional features in its fenestration, such as louver and pergolas to retain a sensation of warm tropical living.
ROOTS RESIDENCE @ GOUYAVE
Project Location: Gouyave, St John's, Grenada
Project Type: Residential
Project Scale: 3,200 Sq. ft.
Project Status: ON THE DRAWING BOARD
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: To be determined
Project Description:
All though non-contemporary this project hold an interesting post colonial vernacular and appears as a home we have all seen before and admired. This is the whole point, that the aim of this project was not to create the new, but to embrace the old, the familiar and go back to the roots of what it feels to be home. Sensation is a positive instrument of architecture and there are times that it is necessary to divorce what is seen in magazines to invoke the familiar senses of what is known to derive a fully sense of satisfaction in a home owner This project is all about roots and country living. As such the architecture is intended to extend on this experience.
RESIDENCE @ OLD WESTERHALL
Project Location: Old Westerhall, St. George's, Grenada
Project Type: Residential
Project Scale: 3,600 Sq. Ft. Dwelling
Project Status: ON THE DRAWING BOARD
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: None
Contractor: To be determined
Project Description:
This is a (3) storey multi-unit (8) bedroom dwelling on a steep and narrow site. It comprises of a (3) bedroom upper level for the Client and (3) rental units on the floors below. This site is particularly challenging to achieve vehicular a to the lower part of the lot compounded with unregulated land erosion form an existing water path. Nevertheless this project promise to be unique to the area, with a fully minimalist contemporary appearance.
TWO SMALL RESIDENCE @ ST. LOIUS CARRIACOU
Project Location: St. Loius, Carriacou, Grenada
Project Type: Residential
Project Scale: (2) App. 1,000 Sq. Ft. Dwellings
Project Status: ON THE DRAWING BOARD
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Peter
Contractor: To be determined
Project Description:
This project is to be situated on a site stunning views of Sandy Island. The Clients being from Eastern Europe requested to small residences with a true tropical architecture with no resemblance to the cold modern architecture of their home land. Weather conditions and sun positions were particularly important in the conceptualization of this project to stick a balance between open living and security and protection.
LIGHTHOUSE DRIVE VILLA & COTTAGES
Project Location: True Blue, St. George's, Grenada
Project Type: Residential
Project Scale: One Villa & Two Cottages with Swimming Pool
Project Status: Under Structural Engineering
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Undisclosed
Client: Confidential
Visualization Artist: None
Contractor: To be determined
Project Description:
This project is to be comprised on a (3) bedroom main villa with (2) single bedroom cottages on a water front coast with a small dark sand rocky beach. These dwellings are to be situated on a long and narrow strip of land are to be of a single storey to be built exclusively out of modular materials and cast concrete.
AIRPORT VIEW VILLA
Project Location: Calliste, St. George's, Grenada
Project Type: Residetial
Project Scale: To be Determined
Project Status: Design Work Cancelled, Not realized
Architect: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Project Description:
This project is on the conceptual drawing board and will be revisited at a later date. The site contains a scenic view unto the airport runway.
As this project is confidential in nature no further description can be given.
THY KINGDOM COME DELIVERANCE SANCTUARY
Project Location: Morne Jaloux, St. George's, Grenada
Project Type: Institutional
Project Scale: 12,000 Sq. Ft. Building
Project Status: Under Construction
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Barry's Engineering
Client: Pastor Happy
Visualization Artist: Undisclosed
Contractor: Self built
Project Description:
This 6,000 Sq. Ft. Church building over two levels on a 10,000 Sq. Ft lot of land, made use of a maximum lot coverage of 60 percent. The location of lot is chosen as a central point to multiple communities strategically to facilitate a larger congregation. This church can accommodate 500-700 people and has auxiliary functions, such as separate spaces for children, services, offices etc. Dynamic latitude was contacted to first seek pre-approval and subsequently full building approval and is currently under construction.
HOFORD RESIDENCE @ EGMONT
Project Location: Petite Calivigny, St. George's, Grenada
Project Type: Residential
Project Scale: 3,500 Sq. Ft.
Project Status: Approved for Construction, Not Active
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: Kishure Fletcher, Caribbean Ideal Designs Architecture & Construction Services Ltd (Phase 1)
Project Description:
This two storey dwelling located on the outskirts of Egmont Development would have an amazing view looking on to Calivigny Island. This design is intended to result a modern looking home with typical traditional features such as a pitch roof design. This project was in the process of construction tendering at the on set of the COVID pandemic. Due to this circumstance and the client's decision to opt for a structural steel superstructure, before the pandemic and the increase of steel price, the budgetary feasibility of the project would be required to be revisited at a later date. The architecture of this dwelling is not elaborate, however the spaces created would be quite comfortable and aerated due to the pitch roof and indeed meet all the necessary comforts on a modest sized dwelling and truly lacking on nothing from the client's perspective.
RESIDENCE @ EMGONT 209
Project Location: Egmont Development, St. George's, Grenada
Project Type: Residential
Project Scale: 2,000 Sq. Ft. Dwelling
Project Status: Under Construction
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: None
Contractor: To be determined
Project Description:
This project at Egmont Lot 209 is a modern traditional home juxtaposed to our contemporary designed home at Egmont Lot 208. This project highlights the fact that each Client is looking for something different and special to their interest. Unlike the project at Lot 208 with several steps this project contained all necessary functions on the upper level on a sloping site to manage and respect some degree of physical disability of the Client. As a guiding principle, architecture is only as good as the utility in brings to occupant. For this project the utility and cultural significance of the design superseded the Architect’s aesthetical values.
RESIDENCE @ MT. PARNASSUS
Project Location: Mt. Parnassus, St. George's, Grenada
Project Type: Residential
Project Scale: 4,000 Sq. Ft. Dwelling
Project Status: ON THE DRAWING BOARD
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: None
Contractor: To be determined
Project Description:
This project we would look forward to as it would mark the first contemporary dwelling with a trending appearance in the Mt. Parnassus area. It is a (5) bedroom house whichhas made excellent use of the topography in the building design accomplishing all of the Client’s spatial requirements within a desired footprint. This building project is to incorporate a strong degree of coloration in external material finishes, green tinted glass fenestration with natural wood.
PAYUMO EXTENSION
Project Location: Molinere, St. George's, Grenada
Project Type: Residential
Project Scale: 800 Sq. Ft. Building Extension (Lower Level)
Project Status: Unrealized
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: None
Contractor: None
Project Description:
This project to be located of the Molinere main road. It is a bottom level of an large existing unfinished home elevated on concrete stilts. The aim starting the proposed bottom level occupying less than 30% over the overall building footprint was to be the precursor for change to the architectural style of the entire residence. The Client desired a contemporary look to an existing traditional building structure which required working within the existing building structural limitations.
GLENELG SPRING WATER PLANT SPACE PLANNING
Project Location: Mt. Rule, St. Patrick's, Grenada
Project Type: Industrial
Project Scale: Internal Space Planning for Existing Plan
Project Status: Implemented
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: None
Client: Glenelg Spring Water Inc.
Visualization Artist: None
Contractor: None
Project Description:
We in past years have been involved in providing architectural consultancy for space planning at the bottling plant at Glenelg Spring Water Inc, located in Mt. Rule St. Patrick’s. During this this period we were engaged to design a 3,000 Sq. Ft. (2) storey Building Extension, Space planning to accommodate a new bottle fill line and blow molder equipment and finally to design and accommodate a supervisor’s production booth.
DA COSTA LOFT
Project Location: Morne Rouge, Grand Anse, St. George's, Grenada
Project Type: Residential
Project Scale: 1,000 Sq. Ft. Building
Project Status: Built
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: None
Contractor: Owner / Builder
Project Description:
This project constitutes a single bedroom unit with loft over a driveway of an existing student rental compound. This project overlooks the Grand Anse Mall and has scenic views to the ocean. The design within was incorporated within a confined space pre-approval as the addition slightly exceeded the allowable building lot coverage. This project was economically built with maximum returns on investment. The Client requested this design for ease of interpretation and execution. This unit was intended for a University professor and is a bit upgraded in the interior fit outs from what is typical for student rental. This project is special as it marks the very first project executed by Lachaba Carr Joseph as Architect Lead although having extensive experience in building project preceding this project.
BROWNSTONE @ MORNE DELICE
Project Location: Morne Delice, St. George's, Grenada
Project Type: Residential
Project Scale: 5,000 Sq. Ft. Building
Project Status: Approved for Construction
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: None
Contractor: None
Project Description:
This project was intended to be (5) bedroom home with typical renaissance features and brownstone finish similar to many dwellings in the Brooklyn area. This dwelling is intended to be the first of it’s kind in Grenada as the Client is a specialist artisan in restoration of Brownstone buildings. Due to the limited external landscape and overall site topography of the site, a decision was made to conserved the project design for another site at a future date.
ISSAC COTTAGE @ CARRIACOU
Project Location: Belle Air, Carriacou, Grenada
Project Type: Residential
Project Scale: 1,500 Sq. Ft. Building
Project Status: Approved for Construction / Resubmission for alternative design done by another Consultant.
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: None
Client: Confidential
Visualization Artist: None
Contractor: None
Project Description:
This project was to be located on 2 acres of secluded land in Belle Air, Carriacou with panoramic views. The concept of this project was to incorporate features of forest dwellings to merge with the heavily wooded surroundings. This project would have incorporated a hybrid wooden skin throughout most of the exterior and a cladded masonry structure to with stand hurricane force winds. This was essential to the Client to have a warmer more traditional wooden finished exterior. However due to changing spatial requirements from the owner although previously approved, alternative downscaled design was resubmitted and approved to be built by another design consultant recommended by Dynamic Latitude.
SPICE ISLE IMAGING CENTER (REAR EXTENSION DESIGN)
Project Location: The Carenage, St. George's, Grenada
Project Type: Health Care
Project Scale: 2,500 Sq. Ft. Rear Building Extension over Two Levels
Project Status: Paused / Discontinued
Project Manager / Healthcare Building Specialist: Confidential
Local Architect of Record: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Confidential
Client: Confidential
Visualization Artist: Undisclosed
Contractor: None
Project Description:
This is intended to be a building extension to accommodate additional medical consultancy units. Our involvement in this project was limited to the preparation of preliminary space planning and coordination with expert healthcare project designer / manager.
As this project is confidential in nature no further description can be given.
MP TRADING BUILDING (MEASURED BUILDING SURVEY + AS-BUILT DRAWINGS)
Project Location: Dusty Highway, Grand Anse, St. George's, Grenada
Project Type: Commercial
Project Scale: Over 20,000 Sq. Ft. Building As-Built
Project Status: Undisclosed
Architect: Undisclosed
Structural Engineer / Structural Draftsperson: Undisclosed
Client: MP Trading Inc.
Visualization Artist: Undisclosed
Contractor: Undisclosed
Project Description:
Our involvement has been limited to preparation of As-Built Drawings for the existing building.
As this project is confidential in nature no further description can be given.
JEWISH CENTER (APPROVAL OF EARTHWORKS)
Project Location: Grand Anse, St. George's, Grenada
Project Type: Institutional
Project Scale: Three storey Synagogue
Project Status: Undisclosed
Architect: Confidential
Structural Engineer / Structural Draftsperson: Confidential
Client: Confidential
Visualization Artist: Undisclosed
Contractor: Undisclosed
Project Description:
Our involvement has been limited to preparation of drawings for approval of earthworks in advance of building works design and submission, which was prepared by foreign based design firm.
As this project is confidential in nature no further description can be given.
RESIDENCE @ EMGONT 179
Project Location: Egmont Development, St. George's, Grenada
Project Type: Residential
Project Scale: 2,000 Sq. Ft. Dwelling
Project Status: On the Drawing Board
Architect: Lachaba Carr Joseph
Structural Engineer / Structural Draftsperson: Lachaba Carr Joseph
Client: Confidential
Visualization Artist: Lachaba Carr Joseph
Contractor: To be determined
Project Description:
